Jefa Aluminium Steering Wheels

Single and tandem spoke aluminium wheels
The Jefa aluminium 6082 steering wheels are unique in the world as the wheels are produced without any welding at all. The hollow spokes are threaded at the hub side and screwed into the hub. At the tapered end the spokes are threaded inside and a through bolt from the outside of the rim is screwed into the threaded spoke. The lack of welding (which dramatically decreases the strength of aluminium) and the unique construction results in an ultra light weight and extremely strong steering wheel with a weight of nearly half on an equivalent stainless steel wheel. As result of the through bolt construction the Jefa aluminium wheels are only available with a fitted leather cover. The wheels in the size from 700 mm up to 1000 mm diameter are available as single spoke version and the wheels from 1100 mm up to 1800 mm are available as tandem spoke version (see pictures). All aluminium wheels come with a 25 mm diameter rim, with the hide cover fitted resulting in a total rim diameter of 29 mm. The available finishes are either white or black powder coating.

Please click on the pictures for a larger view.
Click for larger view Click for larger view Click for larger view
Click for larger view Click for larger view Click for larger view

Aluminium single spoke steering wheels with leather cover, white or black powder coated

Part No.

Description

WHS0700A

Single spoke Aluminium wheel 700 mm with leather cover

WHS0800A

Single spoke Aluminium wheel 800 mm with leather cover

WHS0900A

Single spoke Aluminium wheel 900 mm with leather cover

WHS1000A

Single spoke Aluminium wheel 1000 mm with leather cover


Aluminium tandem spoke steering wheels with leather cover, white or black powder coated

Part No.

Description

WHT1000A

Tandem spoke Aluminium wheel 1000 mm with leather cover
WHT1100A

Tandem spoke Aluminium wheel 1100 mm with leather cover
WHT1200A

Tandem spoke Aluminium wheel 1200 mm with leather cover
WHT1300A

Tandem spoke Aluminium wheel 1300 mm with leather cover
WHT1400A

Tandem spoke Aluminium wheel 1400 mm with leather cover
WHT1500A

Tandem spoke Aluminium wheel 1500 mm with leather cover
WHT1600A

Tandem spoke Aluminium wheel 1600 mm with leather cover
WHT1700A

Tandem spoke Aluminium wheel 1700 mm with leather cover
WHT1800A

Tandem spoke Aluminium wheel 1800 mm with leather cover
The Jefa steering wheel tapers and hubs
All wheels up to 1500 mm have the 25 mm steering shaft taper, from 1600 mm diameter onwards the wheels have the 30 mm taper. All pedestals have the 25 mm shaft and some bulkhead steerers (BS30) and transmission steering boxes are build with the 30 mm steering shaft. Below you will find a drawing of the tapers and the wheel hubs with the distance - start of taper to wheel centre line - .

Cone adapter for hydraulic pumps
All wheels up to 1500 mm can be fitted with an adapter cone for a hydraulic pump with the "small cone" as in below sketch.

Cone adapter

Part No.

Description

WHSADAP

Adapter petit cone - 8,28 degr.
Wheel protecting covers
Wheel protection covers are available for wheel from 1000 to 1100 mm. They are made from neoprene, water and sun resistant and available in the color black.
Example of a 1000 mm wheel cover.
click on the picture for a larger view		 Example of a 1000 mm wheel cover.
click on the picture for a larger view

Jefa Wheel Covers

Part No.

Description

WC1000

Wheel cover for Ø1000 mm steering wheel

WC1100

Wheel cover for Ø1100 mm steering wheel
Quick release wheel nut for fast wheel removal
The quick release nut is very handy when the steering wheel obstructs the free passage in the cockpit. It replaces the standard wheel nut and can be operated with a standard winch handle. This way the steering wheel can be quickly removed when not needed.

Quick Release Steering Wheel Nuts

Part No.

Description

NQS58

Quick release wheel nut for standard wheels

NQT58

Quick release wheel nut for tandem and carbon wheels*¹
*¹: When the steering shaft is Ø30 mm (large taper) in stead of Ø25 (small taper), the standard quick release nut NQS58 should be used.


Ø1500 mm aluminium white tandem wheel on Elan E340


Ø1500 mm aluminium white tandem wheel on Elan E340


Ø1600 mm aluminium black tandem wheel on Elan E410


Ø1600 mm aluminium black tandem wheel on Elan E410


Ø1000 mm aluminium black wheel on MAT 12


Ø800 mm aluminium black single spoke wheel on the Salona 44


Ø800 mm aluminium black single spoke wheel on the Salona 44


Ø1000 mm aluminium black single spoke wheel


Ø1500 mm black tandem aluminium wheel on Winner 1220


Ø1500 mm black tandem aluminium wheel on Winner 1220


Ø1500 mm black tandem aluminium wheel on Winner 1220


Ø1500 mm black tandem aluminium wheel on Winner 1220


Ø1000 mm aluminium tandem wheel on a Sunbeam Yacht


Ø1000 mm aluminium tandem wheel on a Saffier 26
